Description
CNC605 is an injector cleaner and tester suitable for GDI, EFI, SFI and other injectors. The injector can be cleaned and tested by simulating the engine condition. It can also be used to clean the fuel injector ad fuel supply system on the vehicle without disassembly. It is ideal for repair and maintenance service centers!
Features:
- Supports cleaning and testing of GDI, EFI, and SFI fuel injectors;
- Utilizes ultrasonic intensive cleaning technology to thoroughly remove carbon deposits and filter screen residues from the fuel injectors;
- Utilizes microcomputer automatic control technology for automatic control of the cleaning and testing process, and real-time monitoring of the key performance of the fuel injectors;
- Equipped with various non-dismantle cleaning connectors, capable of non-dismantle cleaning and maintenance for multiple vehicle models;
- Through simulating engine operating conditions, comprehensively tests various aspects of the fuel injector’s performance
Functions:
- Working Mode Selection: Can select GDI or EFI working mode based on the injector type.
- Ultrasonic Cleaning: Capable of simultaneously ultrasonic cleaning multiple injectors, effectively removing carbon buildup.
- Uniformity/Spray Testing Function: Detects the uniformity of fuel injection quantity for each injector and allows comprehensive observation of the injector spray pattern using background lighting.
- Sealing Test Function: Tests the sealing and leakage of injectors under system pressure.
- Fuel Injection Quantity Detection Function: Measures the fuel injection quantity of injectors under a constant 15-second injection condition.
- Automatic Cleaning and Testing Function: Under specific working parameters, realistically simulates injector testing under various conditions.
- Reverse Flush Function: For the uniformity/spray testing item, performs a reverse flush using a reverse flush adapter to remove internal injector contaminants and residues attached to the filter screen.
- Non-Dismantle Cleaning Function: Equipped with various non-dismantle cleaning adapters, allowing non-dismantle cleaning and maintenance for multiple vehicle models.
- Optional Side Feeding Adaptor Kits.
Specifications:
- Power supply: AC220V±10%, 50Hz;
- Input power: 350W;
- Ultrasonic cleaner power: 100W;
- Fuel pressure: 0.1～10bar
- Air inlet pressure: 5～8bar
- Simulated RPM range: 10～9990rpm (step length: 100rpm)
- Timer range: 1～30min;
- Pulse width: 0.5～25ms (step length 0.1 ms)
- Operating Volume: 3000ml
- Dimensions: 442mm×490mm×533mm;
