Description
The X-431 PAD V LINK is a high-end professional diagnostic tool with charging base newly developed based on the Android 7.1 open system. It comes with ADAS calibration functions, 41 service functions, TPMS services, and other extended modules functions. The IP65 case is waterproof and dustproof to best protect the scan tool for use longer. All these unique features will offer you a luxury experience of vehicle diagnosis.
Features:
- 3-year free software update
- Topology mapping lets you visual check the DTCs and all systems communication status.
- Enables you to diagnose light, medium & heavy duty (optional) vehicles with the Smarlink C.
- Supports X-431 Fix database to fix the problems fast.
- Full system vehicle coverage for Australian, U.S., Asian and European markets over 110 manufacturers, which is continually updated.
- Real-time voltage display is supported, which helps you monitor the voltage condition of the vehicle during the diagnosis.
- Supports automotive communication protocols CAN/CANFD/DoIP and automotive communication standards J2534/D-PDU/RP1210.
- Auto-detects the communication protocols of the vehicle to check if there is any OBDII port pins damaged or not.
- Intelligent diagnostic enables automatic VIN identity to automatically access systems quickly.
- Intelligent and local diagnostic, which include full diagnostic functions, such as read/clear DTC, live data streaming, bi-directional control, coding, programming, etc.
- Smartlink 2.0 VCI is capable of Remote diagnosis function via Launch remote diagnostic platform (Fees apply)
- Guided functions for Volkswagen and Audi.
- ADAS ready calibration function enables more revenue (ADAS license fee may apply).
- Advanced online coding and programming function.
- An extended solution to support TPMS service.
- The optional software is available to purchase separately on the MALL at any time.
- Built-in repair information and training videos help to track and fix issues fast
41 Special Functions:
Specifications:
| X-431 PAD V LINK | |
| Operation System | Android 11 |
| Display | 10.1″, 1920*1200 sunlight readable screen, gorilla glass |
| CPU | 2.0GHz, Octa-core |
| Memory | 4GB |
| Storage | 256GB |
| Battery | 9360 mAh |
| Camera | Rear 13MP, Front 8MP |
| VCI Connection | 2.4GHz/5GHz dual WiFi |
| Dimension | 320*211*46 mm |
| Interface | TYPE A*1 & TYPE C*1 |
| SMARTLINK C V2.0 | |
| Display | 3.95”, 320*480 |
| Memory | 256M |
| Storage | 8GB |
| Remote Communication | Local Diagnosis: WiFi/BT/USB
SmartLink Remote Diagnosis: WiFi/Ethernet |
| Working Voltage | 9V DC ~ 36V DC |
| Dimension | 200*110*47 mm |
